Jyoti Steels is a reputable manufacturer and supplier of Maraging 250/300/350 Sheets and Plates in Mumbai, India, catering to critical industries with high-performance material. Our Maraging steel products are designed for superior strength, toughness, and dimensional stability for high-stress applications. With an emphasis on quality and accuracy, Jyoti Steels provides dependable sheets and plates meeting rigorous aerospace, defense, and tooling requirements. Supported by state-of-the-art production facilities and customer-centric approach, we offer custom solutions for high-demand industrial applications in India and overseas markets.
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Standard : | AMS, AMS, API |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Weight% | Ni | Co | Mn | Si | C | Al | Mo | S | P | Ti | Fe | Cr | Cu |
| C250 | 17.0 / 19.0 | 7.0 / 8.5 | 0.10 max | 0.10 max | 0.03 max | 0.05 / 0.15 | 4.6 / 5.2 | 0.010 max | 0.010 max | 0.3 / 0.5 | Bal | 0.50 | 0.50 |
| Weight% | C | Si | Mn | S | P | Co | Ni | Mo | Ti | Al | Fe |
| Maraging 300 | 0.03 max | 0.10 max | 0.10 max | 0.010 max | 0.010 max | 8.0-9.5 | 18.0-19.0 | 4.6-5.2 | 0.55-0.80 | 0.05-0.15 | Bal |
| Weight% | Ni | Co | Mn | Si | C | B | P | S | Al | Mo | Ti | Zr |
| Maraging 350 | 18.50 | 12.0 | 0.10 max | 0.10 max | 0.03 max | 0.003 | 0.01 max | 0.01 max | 0.10 | 4.8 | 1.40 | 0.01 |
| Material | Condition | Ultimate Tensile (min) | Yield Strength (Min) | Elongation in 4D % (min) | Hardness | ||
| Mpa | Ksi | Mpa | Ksi | ||||
| Alloy Maraging C250 | After Maraging heat treatment 900°F | 1758 | 255 | 1724 | 250 | 6 | ≥ 48 HRC |
| Material | 0.2 % Yield Strength ksi | Ultimate Tensile Strength ksi | Elongation in 4D(%) | Reduction of Area % | Hardness Rc |
| Maraging 300, Solution Annealed 1500° F (816°C), 1hr, AC | 120 | 150 | 16 | 70 | 30 |
| Solution Annealed Plus Aged 900 ° F (482°C), 3 hrs AC | 280 | 290 | 8 | 40 | 52 |
| Material | 0.2 % Yield Strength ksi | Ultimate Tensile Strength ksi | Elongation in 4D(%) |
| Maraging 350 | 330 | 350 | 8 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Maraging 250/300/350 Sheets and Plates are extensively utilized in aerospace structures, missile cases, rocket motor cases, and landing gear parts owing to their outstanding strength-to-weight ratio and toughness against fracture. In the tooling sector, they are employed for die casting molds, extrusion dies, and high-performance injection molds, providing superior wear resistance and machinability. Defense and nuclear industries utilize them in structural components and containment systems. Their strength retention upon heat treatment and deformation resistance also qualify them for use in safety-critical parts of motorsports, industrial equipment, and precision machinery.
