Jyoti Steels is a prominent manufacturer and supplier of Alloy C263 Foil from Mumbai, India, that is recognized for providing high-quality high-temperature nickel-based alloy products. Our Alloy C263 Foils are designed to function under severe thermal and mechanical strain in a reliable manner, thus found ideal for aerospace, turbine, and industrial purposes. With a promise of accuracy and global quality norms, Jyoti Steels provides customized solutions to address specific client needs. We provide assured delivery, excellent product consistency, and committed customer care in domestic and international markets.
Alloy C263 Foil is a nickel-cobalt-chromium-molybdenum superalloy consisting of Nickel (50–55%), Cobalt (19–21%), Chromium (19–21%), Molybdenum (5.6–6.1%), Titanium (1.9–2.4%), and Iron (up to 0.7%), with minor traces of Carbon, Aluminum, and Boron. Mechanically, it possesses a tensile strength of around 130–140 ksi and superior creep resistance up to 760°C. The alloy’s density is 8.36 g/cm³ and its melting point is around 1355°C. Alloy C263 has good weldability, oxidation resistance, and high-temperature strength, which makes it suitable for use in applications that need formability and long-term stability under severe conditions.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Foil in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Foil is commonly applied in applications that need good high-temperature strength, oxidation resistance, and formability. In the aerospace sector, it is utilized in combustion cans, turbine casings, and exhaust systems. The gas turbine industry utilizes it for hot section parts because of its greater creep and fatigue strength. It is also useful in chemical process hardware, power plant equipment, and heat shields for vehicles. The thin profile and ruggedness of the foil qualify it for thermal insulation, exhaust linings, and sealing. Its reliability under thermal and mechanical stress guarantees consistency in mission-critical applications.
