Mumbai, India-based Jyoti Steels is a prominent producer and supplier of Beryllium Copper Foil Sheets and Plates, providing high–quality products that are renowned for their exceptional strength, superior electrical conductivity, and outstanding corrosion resistance. Committed to quality and accuracy, Jyoti Steels caters to various industries such as aerospace, electronics, automotive, and tooling. The Beryllium Copper products of the company are designed to satisfy stringent industrial requirements and come in a range of sizes and thicknesses, providing consistent performance in high-stress and critical applications in domestic and overseas markets.
Beryllium Copper Foil Sheets and Plates generally consist of approximately 1.8–2.0% Beryllium, 0.3% Cobalt, and the remainder Copper (approx. 97.7–97.9%). This alloy has a high tensile strength of 1100–1400 MPa, yield strength of approximately 700 MPa, and good hardness (up to 38–44 HRC following heat treatment). It has good electrical conductivity of 22–28% IACS and density of about 8.26 g/cm³. The alloy has a melting point of around 870°C to 980°C, good fatigue strength, and non-magnetic behavior, which makes it suitable for precision electronic and mechanical parts.
| Standard Specification : | ASTM B194 / ASME B194 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Beryllium Copper Foil in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Beryllium Copper Foil Sheets and Plates find extensive use in applications requiring high strength, conductivity, and corrosion resistance. In electronics, they are used in connectors, switch contacts, and relays owing to their superior electrical performance. Aerospace and defense industries utilize them for precision devices and parts that need durability and stability under stress. They are also useful in the automotive industry for sensor components and springs, as well as mold making and tooling where hardness and thermal conductivity are crucial. Their non-sparking and non-magnetic properties make them perfect for dangerous environments.
