Jyoti Steels is a reliable maker and supplier of Kovar Foil in Mumbai, India, supplying precision-machined material to industries that require high dependability and heat stability. A well-established firm in supplying special alloys, Jyoti Steels offers best-quality Kovar Foil specially designed for electronic, aerospace, and medical devices applications. The emphasis on quality, dimensional integrity, and customer satisfaction by the company has attributed to a high profile in domestic and foreign markets, wherein it becomes the supplier of choice for critical thermal expansion-matched parts.
Kovar Foil consists of Iron (balance), Nickel (29.0%), and Cobalt (17.0%) along with trace amounts of Manganese (0.5%), Silicon (0.2%), and Carbon (0.02%). It possesses a controlled thermal coefficient of expansion (~5.0 ppm/°C from 20°C to 200°C), well-suited to glass and ceramic matching materials. The foil has a tensile strength of around 520 MPa, yield strength of 415 MPa, and elongation of 25%. Its density is 8.36 g/cm³ with a melting point of approximately 1450°C. Kovar has high dimensional stability and electrical conductivity and so is ideal for fine, high-precision uses.
| Standard Specification : | UNS K94610 | Werkstoff Nr 1.3981 | DIN 17745 | ASTM F15 | AMS 7726 | AFNOR NF A54-301 | S.E.W 385 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condition | Yield Strength (0.1% Offset) | Tensile Strength | Elongation % | ||
|---|---|---|---|---|---|---|
| psi | MPa | psi | MPa | |||
| Alloy K Kovar | Annealed | 49,000 | 340 | 75,000 | 520 | 42 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Kovar Foil finds vast applications in the electronics field for hermetic sealing of glass-to-metal and ceramic-to-metal parts, for example, transistors, diodes, and vacuum tube envelopes. In aerospace and defense applications, it is absolutely essential for packaging sensitive sensors and instruments that demand thermal stability. In medical devices, it is employed in implantable electronics and diagnostic tools on account of its dependability and low outgassing characteristics. In addition, it also serves the telecommunication industry in microwave packaging and relay systems. Its unparalleled control of thermal expansion makes it irreplaceable in high-reliability and precision-engineered assemblies.
