Jyoti Steels, Mumbai, India-based, is a reliable manufacturer and exporter of high-strength Nitinol Shape Memory Tubes with special shape memory and superelastic characteristics. With emphasis on precision engineering and international standards, Jyoti Steels supplies Nitinol tubes with superior performance in critical medical, aerospace, and industrial use. Their state-of-the-art manufacturing capacity provides consistent product deliverability, and hence they are a favored supplier among clients who require innovative, long-lasting, and high-performance tubing solutions to accommodate sophisticated operational requirements.
Nitinol Shape Memory Tubes mostly consist of almost equal proportions of nickel and titanium in the form of 55–56% nickel and 44–45% titanium. Such specific content allows the alloy to display shape memory as well as superelasticity. Mechanically, Nitinol tubes are extremely fatigue-resistant with tensile strengths of 750–1000 MPa, and elongation of up to 10–15%. They are physically very dense, at around 6.45 g/cm³, and undergo phase transformation from martensite to austenite, usually close to body temperature. These make the tubes self-recoverable to their initial shape upon deformation when subjected to a certain range of temperatures.
| Standards : | ASTM F2063 / ASME SF2063 |
| Wall Thickness : | 0.05 mm-3mm |
| Outer Diameter : | 0.70mm~3.00mm |
| Property: | Shape Memory Alloy |
| Condition : | Annealing |
| Af range : | -5 to 40 ℃ |
| Length range : | 500-1800mm |
| Wall Thickness Range : | 0.05 mm-3mm |
| Grade | Ni | C | Co | Cu | Cr | H | Fe | Nb | N | O | Ti |
| Nitinol | 55.6 | 0.037 | 0.004 | 0.005 | 0.002 | 0.002 | 0.012 | 0.005 | 0.005 | 0.035 | Balance |
| Element | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation (%) |
| Nitinol Tube | 1450 | 445 | 17 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| STANDARD | UNS | ASTM |
| NiTi Alloys | N01555 | ASTM F2063 |
Nitinol Shape Memory Tubes are extensively used in medical implants like stents, catheters, and surgical devices because of their biocompatibility and tendency to revert back to a previously set shape. In aerospace engineering, they find application in actuators, couplings, and temperature-sensitive instruments. Industrial applications involve robotic devices, heat engines, and smart connectors where a degree of flexibility and accuracy are necessary. Their superelastic properties permit them to resist mechanical stress without undergoing permanent deformation, and thus they are well suited for dynamic situations. Tubes are also used in orthodontics and spectacle frames, taking advantage of their elasticity, flexibility, and consistent action under changing conditions.
