Jyoti Steels is a leading manufacturer and supplier of Permalloy Foil in Mumbai, India. With expertise in high-permeability magnetic alloys, Jyoti Steels provides precision-rolled permalloy foils for applications in sensitive electronic and magnetic uses. The foils provide excellent magnetic properties, corrosion resistance, and flexibility. Used extensively in aerospace, electronics, medical, and telecommunications industries, Permalloy Foil from Jyoti Steels provides consistent performance and quality. With an emphasis on innovation, timely delivery, and customer satisfaction, Jyoti Steels has gained credibility in domestic as well as overseas markets.
Permalloy Foil is usually about 80% Nickel and 20% Iron, but different grades may have variations (e.g., Ni 45–81%, Fe balance). Trace elements such as Mo ≤ 5%, Mn ≤ 1%, and Si ≤ 0.3% may also be present. Permalloy provides high magnetic permeability, low coercivity, and saturation induction ~0.8 T. In terms of mechanical properties, it has a tensile strength of 400–700 MPa and elongation up to 30%. Physically, it has a density of ~8.7 g/cm³, a Curie temperature of about 450°C, and good formability, which makes it suitable for magnetic shielding and precision parts.
| Standard Specification : | |
| Dimensions : | – |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo | Fe |
| 1J50 | 0.010 | 0.17 | 0.35 | 0.006 | 0.005 | 49.80 | 0.02 | —— | Bal |
| 1J79 | 0.010 | 0.38 | 0.85 | 0.005 | 0.003 | 79.50 | 0.02 | 3.95 | Bal |
| 1J85 | 0.010 | 0.18 | 0.35 | 0.005 | 0.003 | 80.30 | 0.02 | 4.95 | Bal |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Permalloy Foil in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Permalloy Foil finds extensive applications in magnetic shielding owing to its excellent magnetic permeability, particularly in electronics to prevent external magnetic fields. It is critical in transformer cores, inductors, magnetic sensors, and sound equipment. In telecommunications, permalloy foils find application in shielding components for clear signals. The aerospace and defense industries employ it for EMI/RFI shielding. Medical equipment like MRI systems depend on permalloy for precise magnetic performance. Furthermore, it is applied in precision instruments, power supplies, and fluxgate magnetometers for managing and guiding magnetic flux effectively.
