Home > Rene 41 Sheets and Plates
Jyoti Steels, a Mumbai-based company in India, is one of the foremost producers and distributors of high-quality Rene 41 Sheets and Plates, renowned for their superior performance in high-temperature and high-stress conditions. With its emphasis on quality, innovation, and precision, Jyoti Steels supplies Rene 41 products that exceed international standards. The company supplies principal industries like aerospace, defense, and power generation with materials that possess exceptional strength, corrosion resistance, and thermal stability. With a focus on excellence and cutting-edge production capability, they are an ideal supplier of high-performance alloy solutions in demanding applications.
Rene 41 Sheets and Plates contain about 54% nickel, 19% chromium, 11% cobalt, 10% molybdenum, 3% titanium, and 1.5% aluminum along with minute amounts of carbon (≤0.09%) and boron (≤0.01%). It provides outstanding mechanical strength and resistance to oxidation. Rene 41 possesses a tensile strength of around 1380 MPa, yield strength of approximately 1030 MPa, and elongation of around 10–15%. It exhibits strength up to a temperature of 870°C. With 8.36 g/cm³ density and excellent creep and fatigue resistance, Rene 41 finds applications in extreme environments where structural integrity is paramount.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Plates and Sheets find wide usage in aerospace parts like jet engine components, afterburner assemblies, and casings for turbines because of its high strength and thermal stability. In the power generation industry, they are found in use in gas turbines and fasteners for high-temperature applications. The resistance of the alloy to thermal fatigue and oxidation makes it an ideal one for use in nuclear reactors as well as high-performance exhaust systems. It is employed in both automobile racing engines and advanced military use. Rene 41‘s mechanical property retention at high temperatures and stress guarantees its worth in high-temperature engineering environments requiring critical applications.
