Jyoti Steels is a trustable producer and distributor of top-quality Tungsten Foil in Mumbai, India. They are known for their quality and precision and produce high-purity tungsten foils customized to suit challenging industrial needs. Made using state-of-the-art techniques, these foils have excellent heat conductivity, high density, and heat as well as corrosion resistance. Jyoti Steels caters to various industries, such as electronics, aerospace, medical, and energy. With emphasis on punctuality, competitive pricing, and international quality, Jyoti Steels is a sought-after source for tungsten solutions in local and international markets.
Tungsten Foil is typically composed of 99.95% or higher pure tungsten, with minimal impurities such as Mo ≤ 0.01%, Fe ≤ 0.002%, Ni ≤ 0.002%, and Si ≤ 0.002%. It offers exceptional mechanical strength with a tensile strength of 700–1000 MPa and hardness of 350–400 HV. The foil is highly ductile in annealed condition. Its physical properties include a density of 19.3 g/cm³, an extremely high melting point of 3422°C, and excellent thermal and electrical conductivity. Tungsten foil performs reliably under extreme temperatures and radiation, making it ideal for high-tech applications.
| Standard Specification : | ASTM B760 / ASME SB760 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Thickness | Width | Length |
|---|---|---|
| 0.05-0.1 | 100 | L |
| 0.10-0.15 | 100 | 200 |
| 0.15-0.20 | 205 | 1000 |
| 0.20-0.25 | 300 | 1000 |
| 0.25-0.30 | 330 | 1000 |
| 0.30-0.50 | 350 | 1000 |
| 0.50-0.80 | 330 | 1000 |
| 0.80-1.0 | 330 | 1000 |
| 1.-1.50 | 300 | 1000 |
| 1.50-3.0 | 300 | 1000 |
| >3.0 | 300 | L |
Tungsten Foil finds applications in numerous high-performance and high-temperature applications. In the electronic sector, they are employed as heat spreaders, shielding compounds, and semiconductor components. Radiation shielding and thermal protection systems of aerospace and military industries utilize them. Medical technologies utilize it as X-ray and CT scan shield due to their high density and radiation absorption ability. In light technology, lamp components and filaments utilize it. It is also applied in vacuum furnaces, thin-film deposition, nuclear energy, and sputtering targets, where resistance to harsh environments and strength are required.
