Jyoti Steels is a reliable manufacturer and supplier of Super Duplex Steel Pipes in Mumbai, India, providing high-quality piping solutions for extremely demanding industrial uses. With superior resistance to corrosion and superior mechanical strength, these pipes are suitable for use in marine, offshore, chemical, and power generation sectors. Jyoti Steels assures all products conform to international standards based on advanced manufacturing processes and strict quality inspections. With a solid dedication to dependability, customizations, and timely delivery, the company has developed a robust reputation among clients within both local and international markets.
Super Duplex Steel Pipes usually contain Chromium (24–26%), Nickel (6–8%), Molybdenum (3–5%), Nitrogen (0.2–0.3%), and Iron (balance), with traces of elements such as Manganese (≤1.2%), Silicon (≤0.8%), and Carbon (≤0.03%). These pipes possess very good mechanical properties with a tensile strength of 750–900 MPa, yield strength of about 550 MPa, and elongation of 25–30%. They have a density of around 7.8 g/cm³ and a melting point of 1350–1450°C. Super Duplex Steel possesses excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, particularly in environments rich in chloride, for which they are perfectly suited to aggressive service conditions.
|
Standard |
: |
ASTM A790 / ASME SA 790 |
|
Type |
: |
Seamless Pipes |
|
Grade |
: |
UNS S32750, UNS 32760 & UNS S32950 |
|
Size |
: |
1/2″NB TO 12 “NB IN |
|
Thickness |
: |
0.5-45mm |
|
Outer Diameter |
: |
6.0-630mm |
|
Dimensions |
: |
OD(6.0-630)*WT(0.5-45)mm |
|
Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80 |
|
Length |
: |
Single Random, Double Random & Cut Length |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
Super Duplex Pipe |
0.030 max |
1.20 max |
0.80 max |
0.035 max |
0.020 max |
24.00 – 26.00 |
3.00 – 5.00 |
6.00 – 8.00 |
0.24 – 0.32 |
|
UNS No |
Grade |
Proof Stress 0.2% (MPa) |
Tensile Strength (MPa) |
Elongation A5(%) |
Hardness Max |
|
|
HB |
HRB |
|||||
|
Super Duplex Steel Pipe |
2507 |
550 |
795 |
15 |
310 |
32* |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Pipe in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Pipes are extensively employed in applications where high strength and better corrosion resistance are required. In offshore oil and gas use, they find application in subsea pipelines, risers, and structural components subjected to seawater and high pressure. They deal with corrosive fluids and gases in chemical and petrochemical industries. Desalination plants and water treatment plants employ them due to their superior chloride-induced corrosion resistance. They are also employed in pressure vessels, heat exchangers, power generation equipment, and pulp and paper processing where long service life, strength, and durability are essential.
