Jyoti Steels is a renowned manufacturer and supplier of Hastelloy Screws in Mumbai, India. With the emphasis on quality and precision, the company provides corrosion-resistant fastening solutions for the most challenging industrial applications. Jyoti Steels supplies industries like chemical processing, marine, aerospace, and power generation. Jyoti Steels’ Hastelloy screws are designed to resist aggressive chemical environments, high temperatures, and mechanical stress. Produced to international standards, these fasteners provide reliability and performance, making Jyoti Steels a choice for fastening requirements in demanding situations.
Hastelloy Screws, especially of grade C22, have approximately 56% Nickel, 20–22.5% Chromium, 12.5–14.5% Molybdenum, 2–6% Iron, and 2.5–3.5% Tungsten. Trace constituents are Cobalt (up to 2.5%) and Manganese (up to 0.5%). These screws offer a tensile strength of around 690 MPa, a yield strength of 283 MPa, and elongation of around 45%. The density is 8.69 g/cm³, while the melting point is between 1350°C and 1400°C. Hastelloy screws have great resistance to crevice corrosion, pitting, and stress corrosion cracking and are extremely reliable in reducing and oxidizing conditions.
| Standard | IS, ANSI, ASTM DIN, ISO, JIS, GB, ASME, BS, UNI and all International Standards |
|---|---|
| Threads: | BSF, UNF METRIC, UNC, BSW or as required |
| Standard | ANSI – American National Standards Institute
|
| Fasteners/ Bolts Size | M10, M4, M16, M36 M2.5, M6, M30, M12, M8, M14, M2, M3, M20, M24, M5 to M160 |
| Length | 3 mm to 200 mm |
| Head drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe etc |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Finishing | Zinc white, (yellow, black, blue), black oxide, Dacroment, Geometry, plated zinc-nickel, anodizing, nickel plated, Stainless steel: Passivated Self-Colour, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, Stainless Steel, some special one like DACROMET and Mechanically Applied coating |
| raw materials of Source | JSPL, Usha Martin, Tata Steel, Mukund Steel, RINL, Dhamm Steel etc. |
| Form | Square, Hex, Threading as per Gauge, Round Etc. |
| Process of Production | M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element |
| Surface Coating |
|
| Packing | IN BULK: pallet, canton, carton / Small Boxs / pallet or customer request |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy Fasteners | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy Fasteners | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Screw in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Screws find very widespread usage in conditions where resistance to severe corrosion, heat, and stress is very significant. In chemical processing plants, they are utilized for fastening equipment operating in contact with acids such as hydrochloric, sulfuric, and nitric acids. When the environment is marine, they ensure safe fastening in saltwater-exposed systems and structures. Aerospace and defense applications utilize Hastelloy screws in parts exposed to high temperatures and corrosive fuels. Power generation plants use them in turbines and high-pressure applications. Also, pharmaceutical and food industries depend on these screws for hygienic, chemical-resistant assembly in processing equipment and cleanroom installations.
