Jyoti Steels is a renowned producer and supplier of Invar 36 Sheet and Plates in Mumbai, India. Established for its excellence in high-performance alloys, the company offers precision-made Invar 36 products for challenging industrial applications. These plates and sheets are made for conditions where minimal thermal expansion is needed, providing unparalleled dimensional stability. Jyoti Steels caters to a broad spectrum of industries such as aerospace, electronics, cryogenics, and tooling, providing products of international standards with surety of reliable quality, prompt supply, and excellent customer service.
Sheets and Plates of Invar 36 consist predominantly of Iron (63.5%) and Nickel (36%), along with small traces of Manganese (≤0.5%), Silicon (≤0.3%), Carbon (≤0.05%), and Chromium (≤0.25%). This alloy possesses low thermal expansion and excellent toughness. Mechanically, it possesses a tensile strength of approximately 490 MPa and yield strength of 240 MPa, with elongation ≥35%. Physical properties consist of a density of 8.1 g/cm³ and a very low coefficient of thermal expansion (about 1.2 × 10⁻⁶ /°C in the temperature range 20–100°C), making it well suited for precision applications.
| Standards : | ASTM F1684 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc |
| Grade | C | Mn | Si | S | Co | Fe | Mo | Al |
| Invar 36 | .008 max | .30 max | .15 max | .001 max | .35 max | 63.0 max | .02 max | .03 max |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 36 | KSI (MPa) 63 / (430) Max | KSI (MPa)-38 / (260) Max | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 36 | 1.3912 | K93600 | K93603 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Invar 36 Plates and Sheets are commonly applied in areas where dimensional stability is important. Some of these include aerospace tooling, satellite parts, precision instruments, and cryogenic storage tanks. In the electronics sector, they find application in shadow masks, laser parts, and integrated circuit tooling because they have negligible expansion when temperature varies. Invar 36 also finds wide application in measurement devices manufacturing, marine systems, and bimetallic thermostats. Its special characteristics render it a perfect material for buildings that need to have close tolerances across different temperatures.
