Jyoti Steels is a reliable manufacturer and supplier of Invar 42 Sheet and Plate in Mumbai, India. Renowned for providing high-precision and high-performance metal solutions, Jyoti Steels is a specialist in supplying Invar 42 products for applications that require low thermal expansion. With advanced manufacturing facilities and rigorous quality control measures, the company offers products that conform to international standards. Supplying industries like electronics, aerospace, and tooling, Jyoti Steels provides reliability, precision, and superior material performance to each customer.
Invar 42 Sheet and Plate is an iron-nickel alloy consisting of about Nickel (41–43%), Iron (balance), traces of Carbon (<0.05%), Manganese (<0.8%), Silicon (<0.3%), and Chromium (<0.25%). It has a very low coefficient of thermal expansion. Mechanically, it provides a tensile strength of ~450 MPa, yield strength of approximately 276 MPa, and elongation of 30%. Physically, Invar 42 has a density of 8.12 g/cm³ and Curie point of ~280°C. Due to its dimensional stability with respect to temperature variations, it is the best material for precision parts.
| Standards : | Per Chem Mil-I-23011C CL 7, Boeing D-33028, ASTM B753, ASTM F1684, ASTM F30 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 42 | KSI (MPa) 36 / (248) | KSI (MPa) 71 / (490) | 40 % |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Density | 0.293 lb/cu in |
| Specific Gravity | 8.12 |
| Curie Temp | 715 oF or 380oC |
| Melting Point | 2600 oF or 1427oC |
| Electrical Resistivity | 66 Micro-ohm-cm or 400 ohm-cir mil/ft |
| Thermal Conductivity | 10.7 W/cm oC or 74.7 BTU-in/sq. ft-hr |
| Specific Heat | 0.12 Cal/g- oC |
| Thermal Expansion | 5.0 ppm / oF (75oF to 842oF) or 9.0 ppm / oC (25oC to 450oC) |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Invar 42 Sheets and Plates find widespread usage in applications involving dimensional stability in response to temperature variation. They are well suited for the production of electronic components such as lead frames, glass-to-metal seals, and thermostat rods. In the aerospace sector, they are applied in satellite structures and precision instruments. Composite mold tooling also employs Invar 42 because of its predictable expansion behavior. Other applications involve laser systems, measuring devices, and cryogenic equipment, where precise tolerances and stability are essential for performance and safety.
