Home >Nimonic 80A Bar
Jyoti Steels is a reliable producer and supplier of Nimonic 80A Bar in Mumbai, India, and it is renowned for supplying high-performance nickel alloys for use under extreme temperature and stress levels. With its reputation as a quality and accurate producer, Jyoti Steels supplies Nimonic 80A bars that exceed rigorous aerospace, power generation, and automobile industry specifications. Supported by cutting-edge technology and customer satisfaction, the company provides reliable supply, consistent quality, and customized solutions for domestic and international customers needing heat-resistant, high-strength alloy bars.
Nimonic 80A Bar is nickel-chromium alloy with Nickel (≥69%), Chromium (19%–21%), Titanium (1.8%–2.7%), and Aluminum (1.0%–1.8%) with trace elements of Carbon (≤0.1%), Iron (≤3%), and Cobalt (≤2%). This alloy provides high mechanical strength and oxidation resistance at high temperatures. Its tensile strength is approximately 1000 MPa, yield strength is 750 MPa, and elongation is about 20%. With a density of 8.19 g/cm³ and melting point of approximately 1354°C, Nimonic 80A retains stability and performance in hot and stress-loaded conditions.
| Standards : | Nimonic 80A Rod, Bar : BS 3076 HR1, ASTM B 637, AECMA PrEn2188, AECMA PrEn2189, AECMA PrEn 2190, AECMA PrEn 2396, AECMA PrEn2397, AIR 9165-37 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic 80A Bar in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nimonic 80A Bar finds extensive use in applications requiring superior strength, creep resistance, and thermal stability at elevated temperatures. In aerospace, it finds application in turbine blades, exhaust valves, and other engine parts. The power generation industry uses Nimonic 80A in gas turbines and heat exchangers. Automotive engines, nuclear reactors, and fasteners for high-temperature applications also use Nimonic 80A. Due to its oxidation and stress deformation resistance, it is best suited for parts under sustained heat and mechanical stress in demanding operating environments.
