Jyoti Steels is a trustworthy manufacturer and exporter of Hastelloy C22 Stud Bolts from Mumbai, India. It is a specialized company that manufactures high-quality fasteners designed for application in extremely corrosive and aggressive environments. With a focus on precision, quality control, and compliance with international standards, Jyoti Steels provides long-lasting Hastelloy C22 Stud Bolts to several industrial sectors. Their materials are extensively used in applications where high resistance to corrosion and mechanical strength is necessary, and therefore they are the first choice of clients in the chemical, marine, and energy sectors.
| Specification | ASTM F468, B574 / ASME SF468, SB574 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C22 Stud Bolts | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy C22 Stud Bolts find applications in chemical processing facilities, petrochemical operations, marine processes, and pollution control equipment. They are perfect for securing equipment that is exposed to aggressive chemicals such as chlorine, sulfuric acid, ferric chlorides, and acetic acid. The bolts find widespread use in heat exchangers, reactors, flue gas scrubbers, and pressure vessels. Their high resistance to crevice corrosion and stress corrosion cracking makes them ideal for use in high-temperature and high-pressure systems. They are also applied in food processing and pharmaceutical industries where there is a need for hygienic and corrosion-resistant fastening to ensure system integrity and conformity.
