Jyoti Steels in Mumbai, India, is a renowned producer and distributor of Hastelloy C22 Tubing with high-performance solutions for applications demanding superior corrosion resistance. Recognized for accuracy and quality dedication, Jyoti Steels delivers Hastelloy C22 tubing that adheres to international standards. These tubes are universally recognized for superior resistance to various corrosive environments, providing reliability and durability for demanding applications. Jyoti Steels continues to provide domestic as well as international customers with excellent quality, durable products that are specially designed to meet industry requirements.
| Inconel Tube Standards | ASTM B622, ASTM B775, ASTM B619, ASTM B626, ASTM B516, ASTM B751 |
|---|---|
| International Specification | din 17751, ISO 6207 |
| Astm B626 Nickel Alloy C22 Welded Tube Size | 6.35 mm To 152 mm OD |
| Astm B622 Hastelloy C22 Seamless Tubing Size | 3.35 mm To 101.6 mm OD |
| Sb 444 Uns N06022 Tubing wall thickness | 0.020″ –0.220″, (custom wall thicknesses available) |
| Astm B622 Hastelloy C22 Tubing Swg & Bwg | 12 Swg., 10 Swg., 16 Swg., 14 Swg., 20 Swg., 18 Swg. |
| Tube Length | Standard & Cut length, Double Random, Single Random Tube |
| Types of Hastelloy C22 Tube | ERW, Seamless, Welded, Fabricated, EFW Tube / Tubing |
| Form | ‘ Hollow, U’ bent, LSAW, Hydraulic, Straight Tube, Boiler, Round, Tube Coil, Square, Rectangular Etc |
| Ams 5581 Tubing Finish | AP (Annealed & Pickled), Polished, MF, BA (Bright & Annealed) |
| Marking | All Hastelloy C22 Tubing are marked as follows: Grade, Standard, Thickness, OD, Heat No., Length (Or according to the customer’s request.) |
| NCF 625 tube End | Beveled End, Plain End, Treaded Tube |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy C22 Tubing finds extensive application across industries like chemical processing, petrochemicals, power generation, and marine services. It is specifically suitable for atmospheres containing harsh chemicals such as sulfuric acid, hydrochloric acid, and chlorine and provides superior pitting and stress corrosion resistance. Typical uses involve heat exchangers, reactors, and piping systems, particularly in those that demand dependable material in high-temperature and corrosive environments. The tubing is used to maintain long-term integrity and performance where other materials will deteriorate.
