Jyoti Steels is a well-established manufacturer and supplier of Hastelloy Tube C276 Fittings from Mumbai, India. Specializing in providing high-quality corrosion-resistant parts, the company supplies superior fittings for aggressive chemical and industrial processes. Jyoti Steels’ fittings are manufactured according to international standards to provide durability, accuracy, and efficient performance under adverse pressure and temperature conditions. Their fittings find extensive application in industries like chemical processing, pharmaceutical, power generation, and naval engineering, establishing Jyoti Steels as a valued partner for dependable piping and tubing services.
| Specifications | ASTM B366 ASME SB366 |
| Size | 6mm to 38mm to 1/4″ to 1 1/2″ |
| Thread | NPT, BSP, BSPT, UNF, ISO, SAE etc. |
| Brass | ASTM B16 ASTM B 453 |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy Tube C276 Fittings | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 Tube Fittings | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy Tube C276 Fittings consist of about Nickel 57%, Molybdenum 15–17%, Chromium 14.5–16.5%, Iron 4–7%, Tungsten 3–4.5%, along with traces of Cobalt <2.5%, Carbon <0.01%, and Silicon <0.08%. These fittings provide a minimum tensile strength of 690 MPa, yield strength of 283 MPa, and elongation of 40–45%. Their physical characteristics are a density of 8.89 g/cm³ and a melting point of approximately 1370°C. The balanced composition of the alloy provides outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking in oxidizing as well as reducing conditions.
Contact us to get a quick quote for your requirement.
Hastelloy Tube C276 Fittings find extensive application in those industries where the high corrosion resistance is of prime importance. These are chemical processing plants, where they deal with hostile media such as hydrochloric and sulfuric acids, power plants, marine environments, and pollution control systems. They are best suited for high-pressure tubing connections in reactors, heat exchangers, condensers, and piping systems. In the food and pharmaceutical industries, their non-reactive and hygienic properties are greatly appreciated. Their resistance to extreme pressures and temperatures guarantees long-term dependability, particularly in fluctuating chemical exposure and corrosive environments.
