Jyoti Steels, based in Mumbai, India, is a reliable producer and distributor of high-quality Sheets and Plates of Nimonic 90, catering to industries that require products withstanding adverse conditions. Renowned for precision engineering and quality adherence, Jyoti Steels provides Nimonic 90 products that possess excellent strength, heat resistance, and resistance to oxidation and corrosion. With sophisticated manufacturing plants and compliance with international standards, the company serves crucial industries like aerospace, power generation, and chemical processing, providing reliable solutions for high-temperature, high-stress applications.
Nimonic 90 Sheets and Plates consist mainly of nickel (~55%), chromium (18–21%), cobalt (15–21%), with trace amounts of titanium (2.0–3.0%), aluminum (1.0–2.0%), iron (≤1.5%), and carbon (≤0.13%). This makes it possess high-temperature strength and superior oxidation resistance. Mechanically, it provides tensile strength of about 965 MPa, yield strength of about 585 MPa, and 20% elongation. Physically, it is 8.18 g/cm³ dense and also keeps performance up to 920°C. The properties of Nimonic 90 make it best suited for environments that need mechanical endurance and resistance to heat.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nimonic 90 Plates and Sheets are widely utilized in aerospace applications including turbine blades, discs, and combustion chambers as a result of their capacity for maintaining strength when exposed to higher temperatures. For power generation purposes, they find application in gas turbines and exhaust systems with high performance. Their corrosion and thermal resistance also places them in suitability for use in chemical plant components, nuclear reactor components, and fasteners exposed to high temperature. Its combination of creep resistance, fatigue strength, and thermal stability ensures mission-critical systems are dependable where failure is unacceptable, and makes it invaluable in challenging engineering environments.
