Mumbai, India-based Jyoti Steels is a reliable manufacturer and supplier of top–notch Super Duplex Steel Coil to industries that require better strength and superior corrosion resistance. Established as a leading supplier of international quality products, Jyoti Steels offers Super Duplex Steel Coils designed to be durable, high-performance, and versatile. Their sophisticated manufacturing techniques and rigorous quality testing guarantee consistency in each coil, and hence they become the first choice as a supplier for usage in various applications across industries like oil and gas, marine, chemicals, and desalination where performance in hostile conditions is essential.
Super Duplex Steel Coil normally has 24–26% chromium, 6–8% nickel, 3–5% molybdenum, 0.2–0.3% nitrogen, and below 0.03% carbon, with the iron as basis and minor additions of manganese, silicon, and copper. This specific chemical composition provides excellent resistance to chloride-induced stress corrosion cracking, pitting, and crevice corrosion. It provides mechanical strength with tensile strength of approximately 800 MPa and yield strength of 550 MPa, together with 25% elongation. Physically, the material is 7.8 g/cm³ in density and possesses good thermal conductivity and structural stability under varying temperature and pressure conditions.
|
Standard |
ASTM A240 / ASME SA240 |
|
Thickness |
0.2mm – 5.0mm |
|
Width |
3.2mm – 1500mm |
|
Length |
AS PER CUSTOMER’S REQUIREMENT |
|
Test Certificate |
Yes |
|
Coils Hardness |
Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
|
Finish |
Hot rolled Coils (HR), Cold rolled Coils (CR), NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
|
Form |
Coil / Strip |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Super Duplex Steel Coils | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| Super Duplex Steel Coils | 7.8 | 0.281 | 1350 | 2460 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Coils in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Coil finds extensive application in offshore and marine sectors for the production of structural parts, pressure vessels, and piping systems subject to seawater exposure. It is well suited for chemical processing plants, desalination plants, and oil refineries where there is a need for high strength and resistance to aggressive media. It is also used in heat exchangers, storage tanks, and pulp and paper equipment. Their superior mechanical properties, resistance to corrosion, and weldability qualify them for use in applications where low maintenance and high performance are needed in corrosive and high-stress conditions.
