Home > Nickel Alloys >AWS Class ENiCrFe-2 Coated Electrodes
Jyoti Steels, a Mumbai, India-based renowned manufacturer and supplier of AWS Class ENiCrFe-2 Coated Electrodes, is known to provide effective welding solutions for high-temperature and corrosion-resistant applications. Our ENiCrFe-2 electrodes are designed to weld Inconel 625 and comparable nickel-chromium-iron alloys, providing excellent strength, ductility, and resistance to hostile chemical environments. These electrodes find extensive applications in petrochemical, power generation, marine, and aerospace industries. Having a quality-focused and performance-driven approach, Jyoti Steels provides uniform and reliable products as per international welding standards and client specifications.
AWS Class ENiCrFe-2 Coated Electrodes consist of around 60–65% Nickel (Ni), 20–23% Chromium (Cr), 8–10% Iron (Fe), 2.5–3.5% Niobium (Nb), and trace amounts of Manganese (Mn ≤1%), Silicon (Si ≤0.5%), and Carbon (C ≤0.10%). These electrodes possess high tensile strength, usually in the range of 760 MPa, yield strength of 550 MPa, and elongation of 30%. They have very good resistance to pitting, crevice corrosion, and stress corrosion cracking. With a density of around 8.44 g/cm³ and a melting point over 1300°C, they are ideal for high-temperature and high-stress conditions with intense oxidizing or reducing conditions.
| Classification | AWS A5.11, A5.1, ENiCrFe-2 |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | Direct Current Electrode Positive (DCEP) |
| Diameters | 3/32”, 1/8”, 5/32”, 3/16” or 2.5mm, Ø 3.2mm, Ø 4.0mm, Ø 5.0mm |
| Size | 2.0mm ∞ 5.0mm |
| AC/DC+ | 50-80, 80-110, 100-135, 140-180 |
| Welding Positions | All positions 5/32” & 3/16” recommended for use in flat & horizontal positions only (F, V, OH, H) |
| AWS ENiCrFe-2 Coated Electrodes Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Cr | Nb+Ta | Mo | Other |
| 0.10 | 1.0-3.5 | 12.0 | 0.03 | 0.02 | 0.75 | 0.50 | 62.0 | 13.0-17.0 | 0.5-3.0 | 0.5-2.5 | 0.50 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ENiCrFe-2 Coated Electrodes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ENiCrFe-2 Coated Electrodes have diverse applications in those industries that require outstanding corrosion and heat resistance. They are well suited for welding nickel-chromium-iron alloys like Inconel 625, and are applied in chemical processing, power generation, offshore drilling, and marine environments. Typical uses include pressure vessels, heat exchangers, reactor components, flue gas scrubbers, and turbine components. These electrodes work particularly well in chlorides-exposed, acids-exposed, and seawater-exposed environments. Their suitability in oxidizing as well as reducing environments is essential to make them important in application for important welds within nuclear plants, aircraft structures, and sea-water distillation facilities.
Jyoti Steels, a premier manufacturer and supplier in Mumbai, India, offers AWS Class ENiCrFe-2 Coated Electrodes renowned for their superior performance in challenging environments. These electrodes are designed for welding nickel-chromium-iron alloys and are ideal for joining dissimilar metals, ensuring high strength and corrosion resistance. With a commitment to quality and innovation, Jyoti Steels provides reliable solutions for industries requiring precision and durability in their welding applications. Choose AWS Class ENiCrFe-2 Coated Electrodes for unmatched performance and longevity.
