Jyoti Steels is a well-known manufacturer and supplier of AWS Class ENiCu-7 Coated Electrodes from Mumbai, India. These electrodes are specifically used for welding nickel-copper alloys, especially Monel alloys, and exhibit high resistance to corrosion in chemical and marine atmospheres. Popular for their smooth arc characteristics and convenience of use, ENiCu-7 electrodes produce tough, ductile welds with low spatter. Jyoti Steels maintains stringent quality control and industry-standard standards, providing dependable and high-performance welding solutions to multiple industries, such as shipbuilding, desalination, chemical processing, and offshore industries.
AWS Class ENiCu-7 Coated Electrodes are mainly composed of Nickel (Ni 65–70%) and Copper (Cu 29–33%) with minor levels of Iron (Fe ≤2.5%), Manganese (Mn ≤2.5%), and Carbon (C ≤0.15%). These electrodes have a tensile strength of about 480–550 MPa and yield strength of 340 MPa, elongation of about 25–35%. Density is around 8.9 g/cm³ and melting point between 1300–1350°C. ENiCu-7 offers very good weldability, particularly for dissimilar metal joints, and maintains strength in sub-zero to moderately high temperatures. Their corrosion resistance in saltwater and reducing acids is of particular importance in severe service conditions.
| Classification | AWS A5.11, A5.1, ENiCu-7 |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | Direct Current Electrode Positive (DCEP) |
| Diameters | 3/32”, 1/8”, 5/32”, 3/16” or 2.5mm, Ø 3.2mm, Ø 4.0mm, Ø 5.0mm |
| Size | 2.0mm ∞ 5.0mm |
| AC/DC+ | 50-80, 80-110, 100-135, 140-180 |
| Welding Positions | All positions 5/32” & 3/16” recommended for use in flat & horizontal positions only (F, V, OH, H) |
| AWS ENiCu-7 Coated Electrodes Application & uses |
|
| C | Mn | P | S | Si | Cu | Nb+Ta | Al | Ti |
| 0.03 | 3.70 | 0.01 | 0.004 | 0.80 | Balance | 0.5-3.0 | 0.09 | 0.60 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ENiCu-7 Coated Electrodes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ENiCu-7 Coated Electrodes are mostly employed to weld Monel alloys (such as Monel 400) and butt weld Monel with other nickel-copper alloys or even carbon steels. These electrodes find extensive application in marine engineering, shipbuilding, desalination plants, chemical and petrochemical processing, and heat exchanger manufacturing. Their superior seawater, brine, and acidic environments resistance positions them well for pump, valve, piping, and condenser repair. They find application in offshore oil rigs, and underwater equipment, where weld lifespan and corrosion resistance are paramount. ENiCu-7 electrodes provide dependable performance in maintenance as well as fabrication operations.
