Mumbai, India-based Jyoti Steels is a leading producer and exporter of AWS Class ENiFe-CI Coated Electrodes, specifically intended for welding cast iron and unlike metals. They have a nickel-iron core wire with high strength and fine fusion properties, particularly for welding gray, ductile, or malleable cast iron. Jyoti Steels provides electrodes with excellent crack resistance, machinability, and arc stability, which makes them suitable for maintenance and repairs. Our attention to quality promotes consistent performance across industries like the automotive, heavy machinery, and foundries segments in India as well as other parts of the world.
AWS Class ENiFe-CI Coated Electrodes have a composition of 55–60% Nickel (Ni), 40–45% Iron (Fe), and trace amounts of Carbon (≤0.15%), Manganese (≤1.0%), and Silicon (≤1.0%). The high tensile strength is around 480–600 MPa, the yield strength is about 350 MPa, while elongation is between 12–18%. These electrodes also provide a melting point of more than 1400°C as well as a density of about 8.2 g/cm³. ENiFe-CI electrodes have very good fusion properties, high crack resistance, and good machinability following welding. They are applicable for both cold and slightly preheated welding, which reduces heat-affected zone cracking in cast iron repair.
| Classification | AWS A5.11, A5.1, ENiFe-Cl |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | Direct Current Electrode Positive (DCEP) |
| Diameters | 3/32”, 1/8”, 5/32”, 3/16” or 2.5mm, Ø 3.2mm, Ø 4.0mm, Ø 5.0mm |
| Size | 2.0mm ∞ 5.0mm |
| AC/DC+ | 50-80, 80-110, 100-135, 140-180 |
| Welding Positions | All positions 5/32” & 3/16” recommended for use in flat & horizontal positions only (F, V, OH, H) |
| AWS ENiFe-Cl Coated Electrodes Application & uses |
|
| C | Mn | Si | S | Fe | Ni+ incidental Cobalt | Cu + incidental Silver | AL | Other |
| 2.0 | 2.5 | 4.0 | 0.03 | Remainder | 45-60 | 2.5 | 1.0 | 1.0 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ENiFe-Cl Coated Electrodes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ENiFe-CI Coated Electrodes have extensive applications for repairing and assembling cast iron parts, particularly when strength and machinability are critical. Typical uses are welding of engine blocks, machine bases, gearbox housings, pump bodies, and other gray or ductile cast iron components. The electrodes are especially useful when dissimilar metal welds (e.g., steel to cast iron) are needed. Their superior crack resistance is especially suitable for cold welding processes and emergency field repairs in the automotive, mining, agricultural, and heavy machinery markets. Post-machining welding is simple, and therefore, they are the first choice for precision fabrications and repair work.
