Jyoti Steels is a well-known producer and supplier of Nickel Alloy 200 Stud Bolts in Mumbai, India, providing premium fasteners that provide superior performance in corrosive, high-temperature, and high-pressure conditions. With a long history and a passion for excellence, Jyoti Steels caters to industries like chemical processing, marine, power generation, and electronics. Their Nickel Alloy 200 Stud Bolts are designed to international standards, providing high mechanical strength, excellent corrosion resistance, and high thermal and electrical conductivity, and are therefore well suited for rigorous industrial use.
Nickel Alloy 200 Stud Bolts consist mainly of ≥99.0% Nickel with trace amounts of Iron ≤0.4%, Manganese ≤0.35%, Silicon ≤0.35%, Copper ≤0.25%, Carbon ≤0.15%, and Sulfur ≤0.01%. These bolts provide tensile strength of approximately 462 MPa and yield strength of 148 MPa, elongation at 45%. Physical properties of these bolts are a density of 8.89 g/cm³ and melting range of 1435–1446°C. These stud bolts have excellent corrosion resistance in reducing and alkaline environments, with high thermal and electrical conductivity, and are therefore dependable for demanding structural applications.
| Grade | Nickel |
| Specifications | ASTM B 160/164, ASME SB 160/164 |
| Dimension | ASTM, IS, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc etc. |
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Nickel | 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Nickel | Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 Stud Bolts have extensive applications in industries requiring high corrosion resistance and mechanical strength. In the chemical industry, they are best suited for application in caustic soda production, acid processing units, and reactors. In the marine industry, they are seawater corrosion-resistant and find application in pumps and valves. Power plants use them in steam systems and heat exchangers, and the electronics sector has the advantage of their conductivity and lower magnetic properties. They are utilized in food processing, pharmaceuticals, and aerospace sectors where resistance to contamination, strength, and temperature are of utmost importance.
