Jyoti Steels is a reliable manufacturer and supplier of Nickel Alloy 201 Stud Bolts in Mumbai, India, providing high-quality fasteners designed to endure challenging industrial conditions. With a name for precision and reliability, Jyoti Steels offers products that conform to international quality standards. Their Nickel Alloy 201 Stud Bolts are perfect for industries demanding exceptional corrosion resistance, strength, and reliability. With their focus on performance and durability, these stud bolts are typically applied in high-purity critical applications where resistance to a number of corrosive chemicals is necessary.
Nickel Alloy 201 Stud Bolts consist of 99% Nickel and traces of Iron (≤0.4%), Manganese (≤0.35%), Silicon (≤0.35%), Copper (≤0.25%), Carbon (≤0.02%), and Sulfur (≤0.01%). These bolts possess a tensile strength of 483 MPa, yield strength of 138 MPa, and elongation of approximately 45%. With a density of 8.89 g/cm³ and a melting point of 1435–1446°C, they perform well under conditions of high temperature and corrosive substances. Nickel Alloy 201 Stud Bolts provide superior resistance to alkaline and reducing surroundings, in addition to high thermal and electric conductivity.
| Grade | Nickel |
| Specifications | ASTM B 160/164, ASME SB 160/164 |
| Dimension | ASTM, IS, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc etc. |
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Nickel | 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Nickel | Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 201 Stud Bolts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 201 Stud Bolts have wide usage where high resistance against corrosion and the mechanical properties withstanding severe conditions are necessary. In chemical processing, they best suit reactors as well as pipeline systems conveying caustic soda or other chemically aggressive environments. In maritime industry applications, these bolts have usage in structures exposed to seawater owing to their chloride stress corrosion resistance. Power plants and electronics industries employ them in high-performance applications, e.g., heat exchangers and turbines, where they maintain consistent, long-lasting performance under harsh high-temperature conditions. They also find applications in food processing and drug equipment.
