Jyoti Steels is a leading producer and supplier of Duplex Steel 2205 Sheet and Plates in Mumbai, India. Well known for reliability, precision, and quality, Jyoti Steels offers sheet and plate solutions capable of enduring extreme and corrosive environments. Jyoti Steels’ 2205 duplex steel products are produced to international standards, with exceptional mechanical strength and corrosion resistance. With state-of-the-art infrastructure and skilled craftsmanship, Jyoti Steels serves the chemical processing, marine, oil & gas, and power generation industries with reliable and economical material for high-performance structural and industrial applications.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| 2205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex 2205 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel 2205 Plates and Sheets are commonly used in applications demanding robust, corrosion-resistant materials. They are well suited for offshore oil and gas platforms, chemical processing plants, marine equipment, and desalination units. The sheets and plates are also applied to heat exchangers, pressure vessels, structural supports, and storage tanks subject to aggressive chemicals and chloride-contaminated environments. Their high resistance to fatigue, erosion, and stress corrosion cracking also makes them appropriate for use in pulp and paper industries, food processing, and petrochemical equipment. Duplex 2205’s long service life and strength make them a suitable and dependable choice for both structural and high-performance applications.
