Home > Duplex Steel > Duplex Steel Wire
Jyoti Steels is a prominent Duplex Steel Wire manufacturer and supplier company based in Mumbai, India. We deliver superior wire solutions for strength, durability, and corrosion resistance in hostile industrial conditions. Being produced to global quality standards, our Duplex Steel Wire is found to be used extensively in marine, chemical, construction, and oil & gas industries. With quality control, precision manufacturing, and timely delivery given prime importance, Jyoti Steels guarantees consistent products of high quality meeting the requirements of domestic as well as international customers for critical structural and engineering applications.
Duplex Steel Wire, usually composed of UNS S32205, has approximately 22% Chromium, 5–6.5% Nickel, 3–3.5% Molybdenum, and 0.14–0.2% Nitrogen, in addition to Manganese (≤2%), Silicon (≤1%), and Carbon (≤0.03%). The above composition offers very good mechanical strength with tensile strength of 620–880 MPa and yield strength of approximately 450 MPa. It has a density of 7.8 g/cm³ and a melting point of approximately 1350°C. Duplex Steel Wire with its ferritic-austenitic microstructure provides excellent stress corrosion cracking resistance, pitting, and crevice corrosion, which makes the wire suitable to be used under aggressive chemical environments and marine exposures.
| Duplex Wire Standard | ASTM A276, A479 / ASME SA276, SA479 AMS 5514 |
|---|---|
| Duplex Steel / Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Duplex Wire Length | Cut Lengths: 0.125″ to 72″ No Limit on Spooled Lengths |
| Duplex Wire Diameter | 0.0004″ to 0.040″ 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
|
580-750 |
|
as standard |
|
28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| S31803 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 21.0 – 23.0 | 4.5- 6.5 | 2.5 – 3.5 | 0.08 – 0.20 |
| S32205 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 22.0 – 23.0 | 4.5- 6.5 | 3.0 – 3.5 | 0.14 – 0.20 |
| Tensile Strength | 650 -850MPa |
| Elongation (Min) | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel Wire in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Applications of Duplex Steel Wire span across various high-strength-demanding industries calling for corrosion resistivity and wearability. These include marine, offshore, applications in chemical processes, oil and gas facilities, and desalination plants. The wire is also employed for welding electrodes, strengthening materials, safety wire, filtration screens, and fencing. Duplex Steel Wire provides resistance to chloride-induced corrosion, making it suitable for seaside and underwater environments. Furthermore, it is employed in construction, automotive, and power generation industries for fasteners and structural supports. Duplex Steel Wire provides long service life, low maintenance, and consistent performance in critical applications.
