Jyoti Steels is a reliable Duplex Steel S32205 Wire manufacturer and supplier based in Mumbai, India. We provide excellent industrial wire renowned for its higher strength, corrosion resistance, and superior workability. Our S32205 wire is produced according to international standards and is utilized extensively across industries like chemical processing, marine, construction, and oil & gas. With an emphasis on precision manufacturing, quality assurance, and customer satisfaction, Jyoti Steels has emerged as a trusted source for long-lasting and efficient duplex stainless steel wire solutions.
Duplex Steel S32205 Wire consists of about 22% Chromium, 5–6.5% Nickel, 3–3.5% Molybdenum, 0.14–0.2% Nitrogen, with additions of Manganese (≤2%), Silicon (≤1%), and Carbon (≤0.03%). This alloy offers great mechanical properties such as a yield strength of about 450 MPa and tensile strength ranging from 620–880 MPa. Density is 7.8 g/cm³ and the melting point is approximately 1350°C. The dual-phase microstructure (ferritic-austenitic) gives better pitting, crevice corrosion, and stress corrosion cracking resistance and makes this wire perfectly suitable to be used in severe chemical and chloride environments.
| Duplex Wire Standard | ASTM A276, A479 / ASME SA276, SA479 AMS 5514 |
|---|---|
| Duplex Steel / Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Duplex Wire Length | Cut Lengths: 0.125″ to 72″ No Limit on Spooled Lengths |
| Duplex Wire Diameter | 0.0004″ to 0.040″ 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
|
580-750 |
|
as standard |
|
28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| S31803 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 21.0 – 23.0 | 4.5- 6.5 | 2.5 – 3.5 | 0.08 – 0.20 |
| S32205 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 22.0 – 23.0 | 4.5- 6.5 | 3.0 – 3.5 | 0.14 – 0.20 |
| Tensile Strength | 650 -850MPa |
| Elongation (Min) | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel S32205 Wire in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel S32205 Wire is applied in several industries owing to its corrosion resistance, long-term reliability, and high strength. It finds extensive use in chemical and petrochemical facilities, heat exchangers, pressure vessels, and marine as well as offshore structures. Duplex Steel S32205 Wire also finds application in reinforcement, welding electrodes, fencing, and architecture. Its chloride stress corrosion cracking resistance enables it to work in coastal, underwater, and desalination applications. Thanks to its formability and good weldability, S32205 wire is ideal for both construction and structural reinforcement where strength and corrosion resistance matter.
