Mumbai, India-based Jyoti Steels is a reliable manufacturer and supplier of high-quality Duplex Steel Sheet and Plates. With their exceptional strength, corrosion resistance, and durability, these plates and sheets are designed to the highest industry standards. Jyoti Steels offers Duplex Steel products for demanding applications in industries such as chemical processing, marine, oil & gas, and construction. With emphasis on quality, timely delivery, and customer satisfaction, Jyoti Steels is the first choice for duplex stainless steel sheet and plate needs in India and international markets.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel Sheet and Plates are used in high–strength and corrosion-resistant requirement industries on a large scale. Typical uses are pressure vessels, heat exchangers, desalination plants, chemical tanks, marine equipment, and offshore structures. They are particularly well-suited to chlorides and aggressive chemicals environments and therefore find particular use in the oil & gas and petrochemical applications. Their better mechanical strength provides weight savings in structural applications, while their corrosion resistance prolongs service life in aggressive environments. They are also used in pulp and paper processing, bridges, and architectural elements where both strength and appearance are significant.
