Jyoti Steels is a renowned manufacturer and supplier of Monel Forged Fittings in Mumbai, India. With its high-performance nickel-copper alloy products, Jyoti Steels offers Monel forged fittings with superior durability and resistance to corrosion suitable for service under extreme conditions. The fitting is carefully engineered to provide high-strength, leakage-proof, and long-term durability for heavy-duty use in aggressive chemical and marine conditions. With a focus on quality, timely delivery, and customer satisfaction, Jyoti Steels supplies industries like oil & gas, petrochemicals, marine, and power generation to India and overseas markets.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Forged Fittings find extensive application in high-stress environments demanding superior corrosion and mechanical properties. In the marine segment, they find use in piping in seawater, pump elements, and valves. The petroleum and gas sector uses them for offshore rigs, refineries, and sour gas systems. They use Monel forged fittings for processing corrosive materials such as hydrochloric and sulfuric acid in chemical processing plants. They also have applications in heat exchangers, condensers, and power generation. Their high strength and resistance to stress corrosion cracking make them suitable for critical connections in aggressive operating conditions.
