Jyoti Steels is a well-established Mumbai-based Monel Pipes manufacturer and supplier renowned for providing superior performance piping solutions that are engineered for challenging industrial applications. Through emphasis on precision, quality, and strength, Jyoti Steels produces Monel Pipes that are made to international standards and serve high-performance sectors including marine, oil & gas, chemical processing, and aerospace. Popular for superior corrosion resistance and mechanical properties, these pipes are best suited for applications involving aggressive media and high pressure, making Jyoti Steels a reliable partner for dependable piping components across sectors.
Monel Pipes consist mostly of Nickel (63–70%) and Copper (28–34%), along with traces of Iron (1–2.5%), Manganese (≤2%), Silicon (≤0.5%), and Carbon (≤0.3%). The alloy provides superior corrosion resistance in seawater and chemical environments. The pipes have a tensile strength of about 550–620 MPa, yield strength of 240–345 MPa, and elongation of 30–35%. Monel Pipes, with a density of 8.8 g/cm³ and a melting range of 1300–1350°C, have high mechanical strength and thermal stability and can be used at ambient as well as elevated temperature applications.
|
Dimensions |
: |
ASTM, ASME and API |
|
Grade |
: |
Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500) |
|
Monel Seamless Pipes |
: |
ASTM B165, ASME SB165 |
|
Monel Welded Pipes |
: |
ASTM B725 / ASME SB725 |
|
Size |
: |
1/8″NB TO 30″NB IN |
|
Specialized in |
: |
Large Diameter Size |
|
Schedule |
: |
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
|
Form |
: |
Round, Hydraulic Etc |
|
Type |
: |
Seamless / ERW / EFW / Welded / Fabricated / CDw |
|
Length |
: |
Single Random, Double Random & Cut Length. |
|
End |
: |
Plain End, Beveled End, Threaded |
| C | Mn | Si | S | Cu | Fe | Ni | Cr | |
| Monel | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Monel | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Pipes in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Pipes are applied widely in industries demanding exceptional corrosion resistance and durability. In the marine industry, they are utilized in seawater systems, heat exchangers, and pump shafts. The oil and gas sector employs them in refinery piping, offshore platforms, and downhole tools. In chemical processing, Monel Pipes deal with acidic and alkaline solutions in reactors and tank storage. Aerospace utilizes them in hydraulic and fuel lines that face harsh conditions. These pipes are also utilized in power generation, nuclear power plants, and defense applications where strength, reliability, and corrosion resistance are paramount for long-term performance.
