Jyoti Steels is a well-known Mumbai-based manufacturer and supplier of Monel Tubing. Jyoti Steels is a specialist in corrosion-resistant nickel-based alloys and provides high-quality Monel tubing for use in extreme conditions and critical fluid transport. The tubes are renowned for their superior resistance to seawater, acids, and alkalis, as well as outstanding mechanical strength. Jyoti Steels caters to major industries such as marine, chemical processing, oil & gas, and power generation. Focusing on precision, strength, and punctual delivery, the company has gained confidence in domestic and global markets.
Monel Tubing consists mainly of Nickel (63% min) and Copper (28–34%), with minor content of Iron (2.5%), Manganese (2%), Silicon (0.5%), and Carbon (0.3%). This material provides better corrosion resistance, particularly in chemical and marine environments. The tubing has a tensile strength of around 550 MPa, yield strength of approximately 240 MPa, and elongation ≥35%, thus providing toughness as well as ductility. The density of Monel is 8.8 g/cm³, and it has a melting point ranging between 1300°C and 1350°C. These mechanical and physical characteristics render Monel tubing suitable for high-temperature, high-pressure, and corrosive conditions of service.
Dimensions | : | ASTM, ASME and API |
Standard | : | ASTM B165/ ASME SB165 |
Size | : | 1/8″NB TO 30″NB IN |
Specialized in | : | Large Diameter Size |
Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Form | : | Round, Hydraulic Etc |
Type | : | Seamless / Fabricated |
Length | : | Single Random, Double Random & Cut Length. |
End | : | Plain End, Beveled End, Threaded |
Cu | Ni | Fe | Mn | C | S | Si | Al |
28.0 – 34.0 | 63.0 min | 1.0 – 2.5 | 2.0 max | 0.3 max | 0.02 max | 0.5 max | 0.50 max |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Tubing finds widespread application in processes where corrosion resistance and high mechanical performance are critical. In the marine sector, it is utilized in seawater cooling systems, condenser tubes, and ballast systems. The oil & gas industry utilizes it in offshore platforms, subsea lines, and heat exchangers for corrosive fluids. In chemical processing, Monel tubing is applied to acid handling, chemical transfer, and reaction vessels. It also occurs in nuclear reactors, aerospace systems, and power plants. Its corrosion resistance, strength, and long life make it the material of choice for harsh environments.
