Jyoti Steels is a well-known manufacturer and supplier of Monel K500 Tubing in Mumbai, India, catering to high-performance tubing solutions that find applications in superior strength and corrosion-resistant applications. With its quality commitment, precision, and timely delivery, Jyoti Steels supplies Monel K500 Tubing in accordance with international specifications, which finds application in demanding sectors like marine, chemical processing, oil & gas, and aerospace. The firm uses superior machinery and trained workers to provide customers with products satisfying the vital conditions of domestic as well as foreign customers.
The Monel K500 Tubing consists of Copper (27–33%) and Nickel (63–70%) with age-hardenability enhancing additives like Aluminum (2.3–3.15%), Titanium (0.35–0.85%), Iron (≤2.0%), and Manganese (≤1.5%). This alloy displays high mechanical strength with tensile strength of up to 965 MPa, yield strength of approximately 690 MPa, and elongation of about 20%. It features a density of 8.44 g/cm³ and melting range of 1315–1350°C. The age-hardened microstructure increases the resistance to corrosion, erosion, and fatigue, making Monel K500 Tubing suitable for applications in high-pressure and high-stress situations.
| Specifications | : | ASTM B163, B730 / ASME SB163, B730 |
| Dimensions | : | ASTM, ASME and API |
Alloy k500 Tubes Size | : | 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk. |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel k500 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel k500 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 Tubing has numerous applications across industries that necessitate corrosion and durability. Marine industries utilize it in seawater piping systems, pump shafts, and sea underwater parts. It is employed in high-pressure tubing for drilling in offshore regions, downhole equipment, and gas lift units in oil and gas operations. It is also employed in chemically processing corrosive fluids to be transported across plants. In aerospace, it‘s used in hydraulic fluid and fuel lines. Its tolerance to harsh environments also qualifies it for use in nuclear reactors and defense where safety and long-term performance are most critical.
