Mumbai, India-headquartered Jyoti Steels is a reputed manufacturer and exporter of high-quality Monel Flanges renowned for their good corrosion-resistant properties and excellent mechanical strength. Emphasizing precise engineering and international quality standards, Jyoti Steels provides an extensive variety of Monel flanges appropriate for harsh applications in marine, chemical plants, oil & gas sectors, and aviation industries. These flanges are made to perform reliably in hostile environments, with long-term durability, dimensional accuracy, and stability against aggressive chemicals and exposure to seawater.
Monel Flanges, generally produced using Monel 400, consist of Nickel (Ni) 63–70% and Copper (Cu) 28–34%, accompanied by trace amounts of Iron (Fe) up to 2.5%), Manganese (Mn) ≤2%), Silicon (Si) ≤0.5%), and Carbon (C) ≤0.3%). These flanges provide tensile strength of 480–620 MPa, yield strength of approximately 170 MPa, and elongation ranging from 30–40%, providing excellent toughness and ductility. The density is roughly 8.8 g/cm³, while the melting point is between 1300–1350°C. Monel flanges demonstrate excellent resistance against seawater, hydrofluoric acid, as well as alkaline solutions at high temperatures and pressures.
| Specifications | Monel 400 Flanges |
|---|---|
| Methods Of Forging | Casting Forging Rolling Cutting |
| DIN Standard | PN6/ PN10/ PN16/ PN25/ PN40/ PN64 |
| Equipment | Pushing Machine Press machine electric bevelling machine |
| Class | Class 150 to 2500. PN 2.5 to PN 250. |
| Use In | Marine & dredging Sanitation Process Instrumentation Oil and Gas Petrochemical/ Refinery/Chemical Power etc. |
| Manufacturing Productivity | 600 ton per month |
| JIS Standard | 5K/ 10K/ 16K 20K/ 30K/ 40K/ 63K |
| Size | 1/2” to 24” (customized diameters: up to 60”.) |
| Face Type | RF (Raised Face), RTJ (Ring Type Joint) |
| EN Standard | 6Bar/ 10Bar/ 16Bar/ 25Bar/ 40Bar |
| Supporting Material For Flanges | Gasket/ Ring Joint/ Flanges Bolts |
| Testing | Hydrostatic testing machine Magnetic particle detector Direct-reading Spectrograph UI trasonic flaw detector |
| Grade | C | Mn | Si | Cu | S | Ti | Ni | Al | Fe |
| Monel 400 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.02 max | – | 63.0 min | 0.50 max | 1.0 – 2.5 |
| Temp° F | Tensile (psi) | .2% Yield (psi) | Elongation in 2” % |
|---|---|---|---|
| 70 | 110,600 | 54,900 | 44 |
| 1000 | 89,000 | 35,600 | 49 |
| 1200 | 83,000 | 35,400 | 54 |
| 1400 | 67,000 | 34,400 | 53 |
| 1600 | 45,000 | 28,200 | 58 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Flanges in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Flanges find extensive application in industries where there is a need for consistent performance in highly corrosive environments. In the marine sector, they are critical in shipbuilding, offshore platforms, and desalination plants because of their resistance to seawater. Chemical processing plants utilize them for piping and vessels that deal with corrosive media. In the oil and gas industry, Monel flanges find application in high-pressure pipelines, refineries, and sour gas service. Apart from that, they are used in power generation, aerospace, and pharmaceutical industries where strength, thermal and corrosion resistance, and reliable connections are indispensable for safe working and efficiency of operations.
