Jyoti Steels is a well-known manufacturer and supplier of Monel 400 Flanges in Mumbai, India. With expertise in high-performance, corrosion-resistant alloy flanges, the company delivers consistent solutions designed for harsh industrial conditions. Monel 400 flanges are popular due to their strength, toughness, and superior resistance to seawater, acids, and alkalis. With an emphasis on quality, accuracy, and timely shipment, Jyoti Steels caters to crucial industries like marine engineering, chemical processing, oil & gas, and power generation, winning the confidence of clients in India as well as overseas.
Monel 400 Flanges consist of Nickel (63% min) and Copper (28–34%), with minute traces of Iron (2.5%), Manganese (2%), Silicon (0.5%), and Carbon (0.3%). This material provides better corrosion resistance in severe environments, such as seawater and acids. The mechanical features are tensile strength of approximately 550 MPa, yield strength of 240 MPa, and elongation ≥35%, providing strength and ductility. Physically, Monel 400 contains a density of 8.8 g/cm³ and melting range of 1300–1350°C, so these flanges are appropriate for high-temperature and high-pressure applications.
Specifications : ASTM B564 / ASTM SB 564
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Size : 1/8″ – 4″
Pressure Ratings :150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Standards : ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc.
| Grade | C | Mn | Si | Cu | S | Ti | Ni | Al | Fe |
| Monel 400 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.02 max | – | 63.0 min | 0.50 max | 1.0 – 2.5 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Flanges in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 Flanges have extensive applications where mechanical strength as well as resistance to corrosion are important. Marine engineering employs them in seawater piping, valves, and pumps. They find application in the oil and gas industry in offshore platforms, refineries, and pipelines that handle aggressive chemicals and saltwater. Chemical processing equipment utilizes them in acid handling equipment and heat exchangers. Power plants and aerospace industries also depend on these flanges for high-stress, high-temperature applications. Their stress corrosion cracking resistance, reliability, and durability make them ideal for long-term industrial applications.
