Mumbai-based Jyoti Steels is a renowned producer and provider of premium-grade Monel 400 Tubing, designed for demanding industrial uses that call for excellent corrosion resistance and tensile strength. With a focus on global quality standards and customer satisfaction, Jyoti Steels provides Monel 400 tubing extensively utilized across marine, chemical processing, oil & gas, and power generation industries. These tubes are suitable for harsh environments and are recognized for their durability, accuracy, and long service life under high pressure, temperature, and corrosive conditions.
Monel 400 Tubing consists of mainly Nickel (Ni) 63–70% and Copper (Cu) 28–34%, and trace elements such as Iron (Fe) up to 2.5%, Manganese (Mn) ≤2%, Silicon (Si) ≤0.5%, and Carbon (C) ≤0.3%. It possesses good mechanical properties with tensile strength of 480–620 MPa, yield strength of about 170 MPa, and elongation of 30–40%. The density of the tubing is 8.8 g/cm³ and its melting point ranges from 1300–1350°C. Known for its toughness and corrosion resistance, Monel 400 tubing performs reliably in both cryogenic and high-temperature applications.
| Specifications | : | ASTM B163, B730 / ASME SB163, B730 |
| Dimensions | : | ASTM, ASME and API |
| Alloy 400 Tubes Size | : | 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk. |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.24max | 28.0-34.0 | 2.50 max | 63.00 min | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Tubing in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 Tubing finds extensive application in those industries where superior corrosion resistance and strength are needed. In the marine sector, it is employed in seawater cooling systems, bilge and ballast piping, and heat exchangers. In chemical and petrochemical plants, it carries corrosive chemicals like hydrofluoric acid and sulfuric acid. The oil and gas industry utilizes it in offshore platforms, process piping, and refinery equipment. It is also employed in nuclear plants, aviation, and pharmaceutical processing systems owing to its consistency in rugged environments, qualifying it for structural as well as fluid handling purposes.
