Jyoti Steels is a well-known producer and supplier of Monel K500 Pipes in Mumbai, India, that offers high-performance nickel-copper alloy products to diverse industries. It is recognized for precision engineering and high-quality standards. Jyoti Steels offers Monel K500 Pipes that combine corrosion resistance with improved strength and hardness. These pipes are produced according to global specifications and are appropriate for critical applications in demanding environments. With a customer satisfaction and timely delivery focus, the company caters to customers from industries such as marine, aerospace, chemical processing, and oil & gas industries.
Monel K500 Pipes consist primarily of Nickel (63-70%) and Copper (27-33%), with minor additions of Aluminum (2.3-3.15%), Titanium (0.35-0.85%), Iron (≤2.0%), and Manganese (≤1.5%). These pipes demonstrate tensile strength of up to 965 MPa, yield strength of about 690 MPa, and elongation of approximately 20%. They contain a density of 8.44 g/cm³ and melting point of between 1315–1350°C. Monel K500 Pipes possess superior corrosion resistance properties of the usual Monel alloys but with additional mechanical strength and hardness because of age-hardening, and these are therefore the best choice in high-stress conditions.
| Specifications | ASTM B 163 ASME SB 163 / ASTM B 165 ASME SB 165 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Size | 15″NB TO 150″NB IN |
| Specialized in | Large Diameter Size |
| Range | 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness. |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
| Monel K500 | Ni | C | Al | Mn | Si | Fe | Cu | S | Ti | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| 63.0 min | 0.25 max | 2.3 – 3.15 | 1.5 max | 0.5 max | 05 – 2 | 27.0 – 33.0 | 0.010 max | 0.35 – 0.85 | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 1,60,000 , MPa – 1100 | 20 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Pipes Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 Pipes are extensively employed in applications involving higher strength and corrosion resistance, particularly in seawater and chemical processing environments. They are perfectly suited for pump shafts, seawater pipes, valves, and heat exchangers. In the oil and gas industry, they find application in drill collars, wellhead components, and downhole tools owing to their ability to withstand sour gas and high-pressure conditions. Aerospace and defense industries use these pipes for structural members and fasteners. Moreover, their superior mechanical properties also allow them to find applications in heavy-load applications within industrial and power generation equipment.
