Home >Super Duplex Steel> Super Duplex Steel Threaded Rod
Jyoti Steels is a premier manufacturer and supplier of Super Duplex Steel Threaded Rods in Mumbai, India, delivering high-performance fastener solutions for challenging industrial uses. Our threaded rods are made from high-quality Super Duplex grades, renowned for their outstanding corrosion resistance, strength, and durability in extreme environmental and mechanical conditions. With accurate threading and compliance with global standards, Jyoti Steels caters to industries like offshore oil & gas, petrochemical, marine, and construction. Our dedication to quality, timely delivery, and customer satisfaction has earned us a reputable name in the domestic and international markets.
Super Duplex Steel Threaded Rods normally contain Chromium (24–26%), Nickel (6–8%), Molybdenum (3–5%), Nitrogen (0.2–0.3%), and Carbon ≤0.03%, and a base of Iron with traces of Manganese and Silicon. It has a composition that gives 750–1000 MPa tensile strength, greater than 550 MPa yield strength, and about 25% elongation. The density is 7.8 g/cm³ and shows good pitting, crevice corrosion, and chloride-induced stress corrosion cracking resistance. Due to their high fatigue strength and thermal conductivity, Super Duplex threaded rods are suited for fastening components in corrosive, high-pressure environments.
| Standard | DIN, ASTM, BS and all International Standards |
| Specifications | ASTM A479 & ASME SA479 |
| UNS S32760 Nut and Bolts Size | M3 To M56 3/6″ to 2″ |
| Length | 3 to 200 MM |
| Super Duplex Steel 2207 Machine Screws Size | M1.6 To M12 |
| Duplex Steel 2205 Washers Size | M3 To M56 3/6″ to 2″ |
| Phosphorus | Sulphur | Silicon | Carbon | Manganese | Nickel | Molybdenum | Nitrogen | Copper | Chromium |
|---|---|---|---|---|---|---|---|---|---|
| 0.035 % max | 0.02 % max | 0.80 % max | 0.03% Max | 1.20 % max | 6.00 – 8.00 % | 3.00 – 5.00 % | 0.24 – 0.32 % | 0.50 % max | 24.0 – 26.0 % |
| Material | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) | Hardness Rockwell C (HR C) |
| Super Duplex Steel Threaded Rod | 760 | 550 | 15 | 32 Max |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Threaded Rod in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Threaded Rods are applied in a variety of structural and fastening applications in industries that involve both high mechanical strength and corrosive resistance. They are needed in offshore platforms, subsea equipment, and marine installations because they are resistant in seawater and high-pressure environments. They are employed in chemical and petrochemical plants to build and fasten reactors, pumps, and flanges. They are also utilized in power plants, desalination facilities, and infrastructure exposed to corrosive chemicals or extreme weather. They are well-suited for mission-critical mechanical and structural assemblies due to their strength and longevity.
