Jyoti Steels is a reliable Tantalum R05240 Sheets and Plates manufacturer and supplier located in Mumbai, India. Dedicated to producing high-purity and precision-engineered materials, Jyoti Steels supplies materials to various industries, such as electronics, aerospace, chemical processing, and medical fields. Their Tantalum R05240 products are produced according to strict international standards, with outstanding corrosion resistance, thermal stability, and mechanical strength. Famous for reliability and quality, Jyoti Steels offers customized solutions to domestic as well as international customers seeking superior materials for high-end applications.
Tantalum R05240 Sheets and Plates consist of unalloyed tantalum with a minimum purity of 99.95%, containing trace amounts of oxygen (max 0.015%), nitrogen (max 0.01%), hydrogen (max 0.0015%), and carbon (max 0.01%). This high-purity grade possesses superior mechanical properties, such as tensile strength of about 200–300 MPa, yield strength of 140–200 MPa, and elongation of 25–30%. Physical properties are a density of 16.6 g/cm³, a melting point of 3017°C, and thermal conductivity of 57 W/m·K. The properties of Tantalum R05240 make it perfect for harsh applications demanding high corrosion and thermal resistance.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05240 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Sheets and Plates Tantalum R05240 have a broad range of applications in chemical processing plant equipment, reactors, heat exchangers, and linings because of its outstanding acid resistance, including sulfuric and hydrochloric acids. They find application in capacitor and high-performance component production in the electronics market. Aerospace and defense industries also employ these products for heat protection and high-temperature parts. Moreover, Tantalum R05240 is applied in the medical industry for surgical tools and implants due to its biocompatibility. Its corrosion resistance, along with its ductility and high melting point, makes it a prime choice for stringent technical applications.
