Jyoti Steels is a renowned Mumbai, India-based manufacturer and supplier of Tantalum Sheets and Plates. With a reputation for providing high-performance materials for specific industrial applications, Jyoti Steels provides tantalum products that offer superior corrosion resistance, high melting points, and excellent durability. The sheets and plates are precision-engineered to international standards and are best suited for industries like chemical processing, aerospace, medical, and electronics. With emphasis on quality, reliability, and prompt delivery, Jyoti Steels serves domestic as well as international markets with professionalism and efficiency.
Tantalum Sheets and Plates are generally made of 99.9% pure tantalum with very small amounts of elements such as oxygen (<0.02%), nitrogen (<0.01%), hydrogen (<0.001%), carbon (<0.01%), and iron (<0.01%). Tantalum possesses a high melting point of 3017°C, density of 16.6 g/cm³, and very good thermal conductivity (~57 W/m·K). It shows remarkable mechanical properties with tensile strength of about 200–750 MPa and elongation up to 30%, depending on processing. Its resistance to corrosion, particularly to acids such as HCl and H2SO4, makes it a good choice for application in very aggressive conditions and high-temperature conditions.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum Plates and Sheets are extensively applied in high corrosion resistance and biocompatibility applications. In the chemical sector, they are employed in linings, heat exchangers, and reactors for dealing with aggressive acids. In electronics, tantalum is utilized in the production of capacitors because of its dielectric stability. Tantalum is utilized in the aerospace industry for high-temperature parts, and in the medical industry for surgical implants and instruments because it is non-reactive. Secondly, it is applied in parts of nuclear reactors and vacuum furnaces, where thermal stability and chemical resistance are required for safe, extended usage.
