Jyoti Steels is a reliable manufacturer and supplier of Tantalum R05255 Sheets and Plates in Mumbai, India, providing high-grade materials customized for mission-critical and high-performance applications. Renowned for accuracy engineering, high-quality standards, and rigorous adherence to international standards, Jyoti Steels provides solutions to various industries such as chemical processing, electronics, and medical equipment manufacturing. The company provides steady supply, great surface finish, and competitive pricing, thus making it a top choice for clients looking for corrosion-resistant and high-temperature products for challenging industrial applications.
Tantalum R05255 Plates and Sheets consist of tantalum alloyed with 2.5% tungsten for greater strength and resistance to corrosion, particularly in hot acidic conditions. The alloy consists of 97.5% tantalum and 2.5% tungsten, trace elements like oxygen ≤ 0.015%, nitrogen ≤ 0.01%, carbon ≤ 0.01%, and hydrogen ≤ 0.0015%. Its density is 16.6 g/cm³, melting point is approximately 3017°C, tensile strength is approximately 450 MPa, and yield strength is around 400 MPa. Its superior formability, heat conductivity, and resistance to harsh chemicals render it suitable for extreme service conditions.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05255 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05255 Sheets and Plates find major applications in the chemical industry for the production of linings, heat exchangers, and vessels dealing with hot, highly corrosive acids like hydrochloric and sulfuric acid. In electronics, they find application in capacitors and vacuum furnace parts because of their high melting point and conductivity. The medical industry employs this alloy for surgical tools and implants because of its biocompatibility. It is also used in aerospace and nuclear industries for critical components that need structural stability, corrosion resistance, and uniform performance at high temperatures.
