Jyoti Steels is a well-established producer and distributor of Tantalum R05400 Sheets and Plates in Mumbai, India, supplying high-purity materials intended to operate accurately in highly corrosive and hot environments. Committed to the highest quality, accuracy, and adherence to global standards, Jyoti Steels supplies Tantalum R05400 sheets and plates widely applied across industries like chemical processing, aerospace, electronics, and medical. Renowned for superior durability and resistance to corrosion, Jyoti Steels‘ tantalum products satisfy the stringent requirements of sophisticated industrial applications in both domestic and international markets.
Tantalum R05400 Sheets and Plates consist of unalloyed tantalum with a minimum purity of 99.9%. Typical chemical composition consists of Tantalum (Ta) ≥ 99.9%, Oxygen ≤ 0.015%, Nitrogen ≤ 0.01%, Hydrogen ≤ 0.0015%, Carbon ≤ 0.01%, and Niobium ≤ 0.1%. These plates and sheets have good mechanical properties like tensile strength of 207 to 750 MPa and elongation of up to 30%. Physical properties are a high melting point of 3017°C, density of 16.65 g/cm³, and good resistance to corrosion, particularly against acids like hydrochloric and sulfuric acid, and hence they are best suited for severe environments.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05400 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05400 Sheets and Plates are widely applied in industries that need strong, corrosion-resistant materials. They are applied in chemical processing to line reactors, columns, and heat exchangers which are facing harsh acids. They are applied in the electronics industry in capacitor anodes and sputtering targets. Aerospace uses them as components for corrosive and high-temperature atmospheres. They are applied in the medical field in surgical implants and instruments because they possess high biocompatibility. These plates and sheets are also used in nuclear reactors and components of vacuum furnaces where corrosion resistance, purity, and strength are crucial.
