Jyoti Steels is a well-known Inconel 600 Pipe Fittings manufacturer and supplier company in Mumbai, India. Having a strong dedication to quality and customer satisfaction, Jyoti Steels supplies high–quality pipe fittings renowned for their excellent corrosion resistance, good tensile strength, and durability. Supported by state-of-the-art manufacturing techniques and a qualified staff, the company supplies to industries across geographies both national and international and is a name to be relied upon in the metal alloy and pipe fitting industry.
Inconel 600 Pipe Fittings consist mostly of Nickel (72%), Chromium (14-17%), and Iron (6-10%) with small quantities of Copper, Manganese, and Silicon. These fittings have very good mechanical properties with tensile strength of approximately 655 MPa and yield strength of about 310 MPa. They have good elongation (up to 45%) and hardness (Rockwell B88). Physically, Inconel 600 has a density of 8.47 g/cm³, a melting point of 1354–1413°C, and very good thermal conductivity, which makes it ideal for high-temperature and corrosive conditions.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Pipe Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Pipe Fittings are used extensively in industries requiring high-temperature resistance and aggressive corrosion resistance, like chemical processing, aerospace, nuclear reactors, marine use, and heat treating equipment. They are well suited for handling acidic and alkaline solutions and food processing applications where hygiene and strength are important. Their durability also qualifies them for use in power generation plants and gas turbine parts, guaranteeing extended service life and low maintenance under harsh operating conditions.
