Jyoti Steels, India Mumbai, is one of the most prominent Inconel Forged Fittings producers and suppliers of high-strength and corrosion-resistant components specially designed for extreme industrial environments. Keeping precision, long life, and international quality in mind, Jyoti Steels supplies products to various industry sectors such as aerospace, oil & gas, power generation, and chemical processing. Their Inconel forged fittings are perfect for high-temperature, high-pressure uses and are relied upon for their performance, dependability, and extended service life in critical applications globally.
Inconel Forgings Fittings, generally Inconel 625 or 718, contain Nickel (Ni) 58–63%, Chromium (Cr) 20–23%, Molybdenum (Mo) 8–10%, Niobium + Tantalum (Nb + Ta) 3.15–5.5%, and Iron (Fe) ≤5%, along with trace elements such as Titanium, Aluminum, Manganese, and Carbon ≤0.08%. These fittings possess superior strength and durability with tensile strength up to 1240 MPa, yield strength approximately 1030 MPa, and elongation of 12–30%. Their density is about 8.44 g/cm³, and they melt between 1290–1350°C, providing excellent mechanical and thermal stability under hostile conditions.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Inconel Forged Fittings find wide application in high-performance applications that need resistance to high temperatures, corrosion, and mechanical stress. In the oil and gas sector, they are used in high-pressure pipelines, subsea equipment, and offshore platforms. Chemical processing plants employ them in acidic and oxidizing conditions for reactors, valves, and piping systems. In the aerospace industry, they are used in fuel and hydraulic systems that are subjected to high heat. Power plants and nuclear power plants depend on them for steam lines, condensers, and cooling systems. Their flexibility and reliability make them perfect for any environment requiring strong, leak-proof performance.
