Jyoti Steels, established in Mumbai, India, is a premier producer and supplier of Inconel 625 Forged Fittings, providing top-quality solutions for high-performance use in corrosive and high-temperature conditions. Renowned for their accuracy engineering and following international quality standards, Jyoti Steels provides forged fittings that provide strength, durability, and resistance to harsh conditions. These fittings are extensively applied in oil & gas, chemical processing, marine, and aerospace industries. In pursuit of reliability and customer satisfaction, Jyoti Steels is a reliable partner for long-lasting and heavy-duty Inconel 625 solutions.
Inconel 625 Forged Fittings are produced from a nickel-based superalloy that has very high strength and corrosion resistance. The chemical composition consists of Nickel (Ni) ≥58%, Chromium (Cr) 20–23%, Molybdenum (Mo) 8–10%, Niobium + Tantalum (Nb + Ta) 3.15–4.15%, Iron (Fe) ≤5%, with trace elements such as Manganese (Mn), Silicon (Si), Aluminum (Al), and Carbon (C ≤0.10%). These fittings have a tensile strength of 827 MPa, yield strength of 414 MPa, and elongation of 30%. The density is 8.44 g/cm³, and the melting range is 1290–1350°C, so they are perfectly suited for harsh conditions.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Forged Fittings are widely utilized in industries where they are frequently exposed to high temperatures and corrosive aggressive agents. In the marine and offshore industry, they find applications in subsea equipment and piping exposed to seawater and chloride-containing environments. In the chemical processing industry, they find applications in acid manufacturing, reactors, and piping systems. Aerospace uses include exhaust systems and engine components because of their high strength at high temperatures. They are also used in nuclear reactors, heat exchangers, and pollution control equipment, where long-term structural integrity is essential under thermal and mechanical stress.
