Jyoti Steels is a leading manufacturer and supplier of Monel Bars based in Mumbai, India, which provides high-quality nickel-copper alloy products to numerous industries. With years of experience and an excellent reputation for dependability, Jyoti Steels supplies Monel Bars that have remarkable corrosion resistance and longevity. The firm follows strict quality checks, timely deliveries, and conformity to international standards, and thus is a reliable source for clients in marine, chemical, and engineering industries both within India and internationally.
Monel Bars are mostly composed of Nickel (63-70%) and Copper (20-29%), with minor quantities of Iron (2.0-2.5%), Manganese (up to 2%), Carbon (max 0.3%), and Silicon (up to 1.5%). Mechanically, they have a tensile strength of approximately 550 MPa, yield strength of 240 MPa, and elongation of 30%. Physically, Monel is 8.8 g/cm³ in density and has a melting range of 1300-1350°C. The bars are noted for their good corrosion resistance in seawater and acidic conditions and good mechanical properties at sub-zero and elevated temperatures.
| Specification | ASTM B164 / ASME SB164 |
|---|---|
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Monel Bars in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Bars find extensive use in high corrosion resistance and strength applications. They are widely applied in marine engineering to propeller shafts, seawater valves, and pumps. In the petrochemical and chemical industries, Monel Bars are used in heat exchangers, chemical processing equipment, and piping systems. Because of their acid and alkali resistance, they are well suited for food processing, oil refining, and chlorinated solvents. Moreover, Monel‘s superior mechanical properties render it suitable for aerospace, electrical components, and fasteners in harsh environments.
