Jyoti Steels is a well-known supplier and manufacturer of Super Duplex Steel S32760 Forged Fittings in Mumbai, India, providing quality–driven solutions designed to withstand harsh industrial conditions. The fittings are specifically created for maximum resistance against corrosion, high strength, and long-term durability under high pressure and temperature. With emphasis on accuracy, quality control, and compliance with international standards, Jyoti Steels serves various industries like oil & gas, petrochemical, desalination, and marine sectors. Our reliability and innovation have established us as a preferred name both domestically and internationally.
| Specifications | ASTM A182 & ASME SA182 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socketweld Fittings |
| Grades | S32750 / S32760/ S32950 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 |
| Grades | Density (g/cm 3) | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15% |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Cu |
| S32760 | 0.030max | 1.20 max | 0.80 max | 0.035max | 0.020 max | 24.0-26.0 | 3.0-5.0 | 6.0-8.0 | 0.24/0.32 | 0.50 |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel S32760 Forged Fittings in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel S32760 Forged Fittings find wide applications on offshore oil rigs, subsea piping systems, chemical processing plants, and in desalination units because of their high resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. These connections are suitable for high-temperature and high-pressure conditions, providing leak-proof and long-lasting pipeline connections. They are also utilized in heat exchangers, pressure vessels, hydraulic systems, and marine structural parts. Due to their high strength-to-weight ratio, better mechanical stability, and resistance to aggressive media, they are the first choice for critical infrastructure in harsh industrial sectors.
