Jyoti Steels is a well-known producer and distributor of Super Duplex Steel Stud Bolts S32760 in Mumbai, India, providing top–quality fastening solutions designed for strength, endurance, and high-corrosion resistance. Jyoti Steels, committed to quality and accuracy, produces stud bolts to exacting international standards, serving mission-critical industries like oil & gas, petrochemical, marine, and offshore. Famed for consistent service and punctual delivery, the firm is a certified partner to industrial customers looking for high-grade fasteners for high-pressure and abrasive environment usage.
Super Duplex Steel Stud Bolts S32760 consist of Chromium (24–26%), Nickel (6–8%), Molybdenum (3–5%), Nitrogen (0.2–0.3%), Tungsten (≤0.7%), and Copper (≤0.5%) with the base being Iron and Carbon content ≤0.03%. These bolts provide outstanding mechanical strength with tensile strength of approximately 800 MPa, yield strength of 550 MPa, and 25% elongation. Physically, they possess a density of 7.8 g/cm³ and melting point of about 1350°C. Their balanced austenitic-ferritic microstructure provides high resistance to stress corrosion cracking, pitting, and crevice corrosion in aggressive and chloride-containing environments.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Steel Stud Bolts S32760 in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Stud Bolts S32760 are extensively used in situations that demand high mechanical strength and corrosion resistance. They form the backbone of offshore oil platforms, subsea pipelines, seawater desalination plants, and marine engineering applications. They are applied in chemical processing equipment, heat exchangers, pressure vessels, and structural assemblies in harsh environments as well. Their capability to resist high pressure, temperature changes, and corrosives qualifies them for pulp and paper mills, power plants, and fire protection systems. S32760 stud bolts guarantee long-term reliability, safety, and low maintenance of critical infrastructure.
