Mumbai, India-based Jyoti Steels is a trusted producer and supplier of top–notch Inconel 600 Sheets and Plates to meet varied industrial requirements both in India and overseas. Highly acclaimed for their strength, oxidation resistance, and thermal stability, these plates and sheets are produced under strict quality control measures. Jyoti Steels supplies Inconel 600 products in various sizes, finishes, and specifications, which are best suited for applications such as aerospace, chemical processing, power generation, and marine use where high endurance in harsh environments is required.
| 600 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 600 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 600 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 600 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 600 Inconel Sheet 3.0–10.0 mm |
| 600 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 600 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 600 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 600 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 600 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 600 Inconel Strips EN 10088 SA -240-600 Strips |
| Finish of Inconel 600 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 600 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Plates and Sheets find extensive application in chemical processing equipment, heat exchangers, aerospace parts, marine hardware, and nuclear reactors because of their very good resistance to oxidation, high-temperature applications, and chloride stress-corrosion cracking. They are perfectly suited for furnace fittings, food processing machines, turbine components, and combustion chambers. Due to their capability of withstanding harsh thermal and chemical conditions, they also find use in seawater and superheater tubes. Inconel 600’s reliability and versatility guarantee that it excels in the most extreme industrial conditions.
