Mumbai, India-based Jyoti Steels is a reliable manufacturer and supplier of high-quality Inconel 601 Sheet and Plates, catering to various industrial segments with precision-engineered solutions. Renowned for their excellence and customer satisfaction, Jyoti Steels offers Inconel 601 products that provide superior performance in corrosive and high-temperature conditions. These plates and sheets are used extensively across industries due to their strength, durability, and resistance to oxidation. With a solid distribution base and technical expertise, Jyoti Steels provides timely delivery and consistent quality to global standards and stringent applications.
| 601 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 601 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 601 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 601 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 601 Inconel Sheet 3.0–10.0 mm |
| 601 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 601 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 601 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 601 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 601 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 601 Inconel Strips EN 10088 SA -240-601 Strips |
| Finish of Inconel 601 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 601 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Sheets and Plates in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Sheets and Plates find large applications in those industries which require enhanced heat and corrosion resistance. They are utilized in furnace hardware, heat treatment baskets, and radiant tubes during thermal processing. Chemicals industries make use of them in reactors, heat exchangers, and process piping owing to their resistant nature towards aggressive media. They are used in aerospace industry applications in exhaust and engine systems. They are utilized in boiler elements and gas turbine components by power plants. They are also applicable for use in marine environments and pollution control systems with durability and performance under harsh operating conditions.
