Jyoti Steels is a prominent manufacturer and supplier of Inconel 601 Fasteners in Mumbai, India, renowned for providing high-performance fastening solutions for demanding industrial applications. These fasteners are designed from high-quality Inconel 601, a nickel-chromium alloy that is well known for its superior resistance to high temperatures and oxidizing conditions. Jyoti Steels guarantees that every Inconel 601 fastener conforms to international quality and is suitable for application in chemical plants, thermal processing equipment, power plants, and aerospace equipment. Through precise manufacturing and assured service, the company caters to customers in India and foreign markets.
Inconel 601 Fasteners are processed from a strength nickel-chromium alloy containing 58–63% Nickel, 21–25% Chromium, and trace amounts of Iron up to a maximum of 14%. They also contain 1.0–1.7% Aluminum, ≤1% Manganese, ≤0.10% Carbon, ≤0.5% Silicon, ≤1% Copper, and ≤0.015% Sulfur. These fasteners have a tensile strength of approximately 600 MPa, yield strength of 240 MPa, and elongation of 30%. It has a density of 8.11 g/cm³ with a melting range of 1360°C to 1411°C. Inconel 601 bolts have superior structure, oxidation resistance, and mechanical properties under harsh temperature and corrosive environments.
| Specifications | ASTM B166 / ASME SB166 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Fasteners in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Fasteners find extensive use in applications involving consistent performance in harsh conditions. In the aerospace industry, they are utilized in jet engine parts, exhaust systems, and heat shields. In the petrochemical and chemical industries, they are used to secure piping and equipment that come in contact with acidic or oxidizing environments. Power generation plants utilize them in boilers, heat exchangers, and turbine assemblies. They are also applied in thermal processing equipment such as furnaces and kilns because they are resistant to scaling and thermal degradation. Inconel 601 fasteners are applied in marine and offshore sectors for their resistance to corrosion in salty, high-moisture conditions.
