Jyoti Steels is a leading manufacturer and distributor of Inconel 617 Nuts from Mumbai, India, providing high-performance fastening solutions to industries that demand strength, durability, and heat resistance. Our Inconel 617 Nuts are specifically designed to operate in harsh environments with higher oxidation and corrosion resistance. Focused on precision manufacturing and compliance with international quality standards, Jyoti Steels caters to customers in aerospace, chemical, petrochemical, and power generation industries. Our dedication to quality, dependability, and timely shipment allows us to become a reliable supplier both domestically and internationally.
Inconel 617 Nuts contain Nickel (44.5–60%), Chromium (20–24%), Cobalt (10–15%), and Molybdenum (8–10%), with minor constituents such as Aluminum (0.8–1.5%), Carbon (max 0.05%), Iron, and Silicon. These nuts possess superior mechanical properties such as tensile strength of approximately 540 MPa, yield strength of 270 MPa, and elongation of 30%. With 8.36 g/cm³ density and a melting interval of 1330–1380°C, Inconel 617 Nuts provide excellent resistance to oxidation, carburization, and creep at high temperatures, providing long-term durability in harsh corrosive and thermal conditions.
Standard ASTM F467, ASTM B564, B166 / ASME SF467, ASME SB564, SB166
Dimensions ANSI B18.2.2, DIN 934,ISO 4032, BS1768, BS 1769
Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads
Size M02 to M160
Type Cold Forged, Hot Forged, Bar Stock Machined, Bar Stock Milling
Length 3 mm to 200 mm
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Jyoti Steels, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Nuts in Mumbai, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 617 Nuts find wide application in high-temperature and corrosive environments in a number of industries. In the aerospace industry, they hold parts subject to extreme heat and stress, including turbine engines and exhaust systems. In power generation, they are suitable for gas turbines, nuclear reactors, and heat recovery systems. Petrochemical and chemical processing facilities use these nuts for high-pressure, high-temperature flange connections. Their outstanding resistance to oxidation and carburization also recommends them for use in furnace fixtures and reformer systems. Inconel 617 Nuts provide structural stability and consistent performance in the most severe operating conditions.
